Albus

Sorry “saneagle” (blasted predictive text!!).

Very many thanks, Antony and seneagle. I’ll give it a go!

Many thanks, Antony. So the Bafang motor itself does not mean that some specialised controller using a particular communication protocol is required (in my research I have come across controllers specifically labelled “ Bafang controller” ) it’s just the connectors I have to look out for?

Good evening everyone. I am new to this forum. I wonder if I may ask for some help (and in doing so please forgive any apparent stupidity on my behalf)? In 2017 I bought an Edge Fat Tyre e-bike. I believe this company is no longer in operaration ( Godaddy states that the edge bike. com domain is for sale). The bike had very little use because of personal circumstances with which I won’t bore you. I‘ve brought my bike out of storage now and decided to get it going. The battery is good and holds a full charge. However the display does not function (ie it is completely dead) and I suspect it has been damaged while in storage. I decided to change the display and so have entered a minefield! I tried a S866 which powers on , shows battery level, and allows me to set 5x PAS levels but the display does not show the speed and the odometer. The bike itself responds to the throttle control and appears to give PAS. From research I know that there can be issues concerning communication between display and controller, but I have tried all 3x protocol settings in P20 without success. I know from reading around that it‘s best to by a matched pair of display and controller ( KT seems to get good reports) but my question is which would be the best to match the motor? I’m not looking for any increase in performance but simply to restore the bike to its original full working order. motor :-Bafang bf rmg06 36v 350w (10) present controller :- LSW 1155 17 2M X1709031447 G3M20211 1592 16 36V 17A” ( I believe LSW indicates Lishui but I’ve not been able to discover anything more about the model number). Very many thanks in anticipation.
